Ubiquiti SR71C 802.11a/b/g/n MIMO Cardbus External Antenna Connectors
UBIQUITI SR71C (10609)
- 802.11a/b/g/n
- MIMO
- Cardbus External
- Antenna Connectors
Ubiquiti SR71C
802.11a/b/g/n MIMO Cardbus External Antenna Connectors
La Siguiente Generación de Poder y Velocidad para Aplicaciones en Exterior. Enlaces a Distancias Kilométricas a 100Mbps+ TCP/IP de Velocidad de Transferencia de Datos.
Información adicional:
| Chipset | Atheros AR9220 with DFS SUPPORT |
| Radio Operation | IEEE 802.11a/b/g/n |
| Interface | 32-bit Cardbus Type II |
| Operation Voltage | 3.3VDC |
| Antenna Ports | (2) MMCX for 2x2 MIMO Operation |
| Temperature Range | -20C to +70C (extended temp version up to +95C) |
| Security | 802.11i with AES-CCM & TKIP Encryption, 802.1x, 64/128/152bit WEP |
| Data Rates | up to 300Mbps |
| TX Channel Width Support | 20MHz / 40MHz |
| RoHS Compliance | YES |
| Hi-Power Frequency Operation | 2412-2462MHz(FCC) , 5475-5725MHz (CE), 5745-5825MHz (FCC) |
| Avg. TX Power ( EIRP ) | Europe: 20dBm ( 100 mW )
Other Countries: 24dBm, +/-2dB |
| Max Avg. Current Consumption | 1.25A, +/-100mA |
| RoHS Compliance | YES |
| Indoor Range (Antenna Dependent) | over 150m |
| Outdoor Range (Antenna Dependent) | over 50km |
| Operating System Support | Linux |
